Razor Barbed Wire Mesh BD-01
BTO-10 BTO-15 BTO-22 BTO-25
Material:Stainless steel 302 304 316 etc. |
Razor Barbed Wire Mesh BD-01
Razor barbed wire mesh is a new kind of protective fencing,
economical cost and practicality and convenient construction.
1.Material:
Galvanized steel sheet and wire or stainless steel sheet and wire
2.Type:
Razor wire flat wrap,
Concertina razor wire,
Rzaor wire mesh fence,
Double concertina razor wire,
Single coil razor barbde wire
3.usage:
Barbed wire minly serves in mines,gardens and apartments,frontier
and sentry defence,and enclosure of prisons.
|
Reference Number |
Blade Style |
Thickness |
Wire Dia. |
Barb
Length |
Barb
Width |
Barb
spacing |
|
BTO-12 |
|
0.5¡À0.05 |
2.5¡À0.1 |
12¡À1 |
15¡À1 |
26¡À1 |
|
BTO-15 |
|
0.5¡À0.05 |
2.5¡À0.1 |
15¡À1 |
15¡À1 |
33¡À1 |
|
BTO-22 |
|
0.5¡À0.05 |
2.5¡À0.1 |
22¡À1 |
15¡À1 |
34¡À1 |
|
BTO-25 |
|
0.5¡À0.05 |
2.5¡À0.1 |
25¡À1 |
16¡À1 |
40¡À1 |
|
BTO-30 |
|
0.5¡À0.05 |
2.5¡À0.1 |
30¡À1 |
18¡À1 |
45¡À1 |
|
BTO-60 |
|
0.6¡À0.05 |
2.5¡À0.1 |
60¡À2 |
32¡À1 |
100¡À2 |
|
BTO-65 |
|
0.6¡À0.05 |
2.5¡À0.1 |
65¡À2 |
21¡À1 |
100¡À2 |
|
Razor Wire Specification:
|
|
Outside Diameter |
No. of Loops |
Standard Length per Coil |
Type |
Notes |
|
450mm |
33 |
8M |
CBT-65 |
Single coil |
|
500mm |
41 |
10M |
CBT-65 |
Single coil |
|
700mm |
41 |
10M |
CBT-65 |
Single coil |
|
960mm |
53 |
13M |
CBT-65 |
Single coil |
|
500mm |
102 |
16M |
BTO-10.15.22 |
Cross type |
|
600mm |
86 |
14M |
BTO-10.15.22 |
Cross type |
|
700mm |
72 |
12M |
BTO-10.15.22 |
Cross type |
|
800mm |
64 |
10M |
BTO-10.15.22 |
Cross type |
|
960mm |
52 |
9M |
BTO-10.15.22 |
Cross type |
